Full specs for Corolla Cross 1.8 GR-S HEV
DIMENSIONS AND CAPACITY
Overall Dimension (mm)	4455 x 1825 x 1620
Wheelbase (mm)	2640
Seating Capacity	5
ENGINE
Engine Type	Hybrid, .4-Cylinder, In-Line, 16-Valve DOHC, Chain Drive with VVT-I
Engine Code	2ZR-FXE
Engine Displacement (cc)	1798
Maximum Output (ps/rpm)	98 / 5,200
Total System Max Output	122
Maximum Torque (Nm/Rpm)	142 /3,600
Fuel Type	Gasoline
Fuel Capacity (L)	36
TRANSMISSION
Transmission	CVT
INTERIOR
Seat Material	Leather (GR-S)
Driver Seat Type & Adjustment	8-Way Power
Passenger Seat Type & Adjustment	4-Way Manual
Rear # 1 Passenger Seat Type & Adjustment	60:40 Split + Reclining
Power Steering	EPS
Steering Wheel Material	Leather-Wrapped
Parking Brake	EPB + Brakehold
Instrument Panel & Center Cluster	Black Soft Touch Panel + Piano Black
Cup/Bottle Holder	2
Inside Rear View Mirror	EC Mirror
Meter Cluster	Digital
Economy Meter	Hybrid System
EXTERIOR
Headlamps	2-Beam LED Projector + Sequential Turn Signal
Daytime Running Lights	LED
Front Fog Lamps	Fr: LED / Rr: LED
Roof Rail	With
Front Windshield Wiper	Rain-Sensing
Rear Windshield Wiper	Intermittent + Washer
Rear Combination Lamps	Smoked LED + Line Guide
Outside Rear View Mirror	Power Adjust + Autofold + Reverse Link + Side Turn Signal
Clearance Lamp	With
Front Grille	Gloss Black
Rear Spoiler	With
Antenna	Fin
Overfenders	With
Moon Roof	Panoramic
FUNCTION
Power Window	Auto Up/Down + Jam Protect
Keyless Entry	With + Smart Entry
Ignition System	Push Start
Airconditioning System	Fr: Auto Dual Zone Climate Control / Rr: A/C Vent
Wireless Charger	With
Rear USB Charger	2
Data Communication Module	With
Drive Mode Select	Eco + Power + EV
Audio System Type	12.3" Audio Display
Audio System Speakers	6
Audio System Smartphone Connectivity	Smartphone Linking + Wireless Apple Carplay + Wireless Android Auto + AM/FM + Bluetooth + Voice Command VViFi
Multi-Information Display (MID)	12.3" Digital
Front USB (Type A and Type C)	Type A: 1 / Type C 1
Connectivity	Smartphone Linking + Wireless Apple Carplay + Wireless Android Auto + AM/FM + Bluetooth + Voice Command VViFi
12v Socket	With
Steering Switches	Audio + Display + Voice + Telephone + Cruise Control + Lane Departure
CHASSIS
Front/Rear Brake	Ventilated Discs/Solid Discs
Tires / Wheels	18" Alloy (GR-S Design)
Suspension	Fr: GR-S MacPherson Strute / Rr: GR-S Torsion Beam
Drivetrain	FVTD
Spare Tires	Temporary Tire
Brake Type	Fr: Ventilated Disc / Rr: Solid Discs
Sta bilizer	With
SAFETY AND SECURITY
Toyota Safety Sense (TSS)	With
Blind Spot Monitor (BSM)	With
Rear Cross Traffic Alert (RCTA)	With
SRS Airbags	Driver + Front Passenger + Driver Knee + Driver Side + Passenger Side + Rear Side + Curtain Shield
Anti-Lock Brake System (ABS)	With
Vehicle Stability Control (VSC)	With
Front Seatbelts	3pt. ELR Pretensioner + Force Limiter
	(2<2)
Rear Seatbelts	3pt. ELR + Force Limiter (x3)
Emergency Brake Signal	With
Toyota Vehicle Security System (TVSS)	Toyota Vehicle Security System
Camera	Panoramic View Monitor
Clearance and Back Sonar	Fr: 4/' Rr:4
Electronic Brake Distribution (EBD)	With
Cruise Control	Dynamic Radar Cruise Control
Pre-collision System (PCS)	Pre-collision System (PCS)
Automatic High Beam (AHB)	With
Lane Tracing Assist (LTD	With
Lane Departure Alert (LDA)	With
OTHERS
Meter Gauge	Full Digital
Audio	Wireless Apple CarPlay & Wireless Android Auto

SPECIFICATIONS

Full specs for Corolla Cross 1.8 V HEV CVT
DIMENSIONS AND CAPACITY
Overall Dimension (mm)	4460 x 1825 x 1620
Wheelbase (mm)	2640
Seating Capacity	5
ENGINE
Engine Type	Hybrid, 4-Cylinder, In-Line, 16-Valve DOHC, Chain Drive with "VT-I
Engine Code	2ZR-FXE
Engine Displacement (cc)	1798
Maximum Output (ps/rpm)	98 / 5,200
Total System Max Output	122
Maximum Torque (Nm/Rpm)	142 /3,600
Fuel Type	Gasoline
Fuel Capacity (L)	36
TRANSMISSION
Transmission	CVT
INTERIOR
Seat Material	Leather + Dark Brown Accent
Driver Seat Type & Adjustment	8-Way Power
Passenger Seat Type & Adjustment	4-Way Manual
Rear #1 Passenger Seat Type & Adjustment	60:40 Split + Reclining
Power Steering	EPS
Steering Wheel Material	Leather-Wrapped
Parking Brake	EPB + Brakehold
Instrument Panel & Center Cluster	Black Soft Touch Panel + Piano Black
Cup/Bottle Holder	2
Inside Rear View Mirror	EC Mirror
Meter Cluster	Digital + Analog
Economy Meter	Hybrid System
EXTERIOR
Headlamps	2-Beam LED Projector + Sequential Turn Signal
Daytime Running Lights	LED
Front Fog Lamps	Fr: LED / Rr: LED
Front Windshield Wiper	Rain-Sensing
Rear Windshield Wiper	Intermittent + Washer
Rear Combination Lamps	LED + Line Guide
Outside Rear View Mirror	Power Adjust + Autofold + Reverse Link + Side Turn Signal
Clearance Lamp	With
Front Grille	Chrome + Dark Gray Paint
Rear Spoiler	With
Antenna	Fin
Overfenders	With
Moon Roof	Panoramic
FUNCTION
Power Window	Auto Up/Down + Jam Protect
Keyless Entry	With + Smart Entry
Ignition System	Push Start
Airconditioning System	Fr: Auto Dual Zone Climate Control / Rr: A/C Vent
Wireless Charger	With
Rear USB Charger	2
Data Communication Module	With
Drive Mode Select	Eco + Power + EV
Audio System Type	12.3" Audio Display
Audio System Speakers	6
Audio System Smartphone Connectivity	Smartphone Linking + Wireless Apple Carplay + Wireless Android Auto + AM/FM + Bluetooth + Voice Command VViFi
Multi-Information Display (MID)	7" TFT
Front USB (Type A and Type C)	Type A: 1 / Type C
Connectivity	Smartphone Linking + Wireless Apple Carplay + Wireless Android Auto + AM/FM + Bluetooth + Voice Command WiFi
12v Socket	With
Steering Switches	Audio + Display + Voice + Telephone + Cruise Control + Lane Departure
CHASSIS
Front/Rear Brake	Ventilated Disc + Solid Disc
Tires / Wheels	225/50 R18 Alloy
Suspension	Fr: MacPherson Strut / Rr: Torsion Beam
Drivetrain	FWD
Spare Tires	Temporary Tire
Brake Type	Fr: Ventilated Disc / Rr: Solid Discs
Sta bilizer	With
SAFETY AND SECURITY
Toyota Safety Sense (TSS)	With
Blind Spot Monitor (BSM)	With
Rear Cross Traffic Alert (RCTA)	With
SRS Airbags	Driver + Front Passenger + Driver Knee Driver Side + Passenger Side + Rear Side + Curtain Shield
Anti-Lock Brake System (ABS)	With
Vehicle Stability Control (VSC)	With
Front Seatbelts	3pt. ELR Pretensioner + Force Limiter (xo
Rear Seatbelts	3pt. ELR + Force Limiter (x3)
Emergency Brake Signal	With
Toyota Vehicle Security System (TVSS)	Toyota Vehicle Security System
Camera	Panoramic View Monitor
Clearance and Back Sonar	Fr: 4 / Rr:4
Electronic Brake Distribution (EBD)	With
Cruise Control	Dynamic Radar Cruise Control
Pre-collision System (PCS)	Pre-collision System (PCS)
Automatic High Beam (AHB)	With
Lane Tracing Assist (LTAO	With
Lane Departure Alert (LDA)	With
OTHERS
Meter Gauge	Digital + Analog
Audio	Wireless Apple CarPlay & Wireless Android Auto

SPECIFICATIONS

Full specs for Corolla Cross 1.8 HEV CVT
DIMENSIONS AND CAPACITY
Overall Dimension (mm)	4460 x 1825 x 1620
Wheelbase (mm)	2640
Seating Capacity	5
ENGINE
Engine Type	Hybrid, .4-Cylinder, In-Line, 16-Valve DOHC, Chain Drive with "VT-I
Engine Code	2ZR-FXE
Engine Displacement (cc)	1798
Maximum Output (ps/rpm)	98 / 5,200
Total System Max Output	122
Maximum Torque (Nm/Rpm)	142 /3,600
Fuel Type	Gasoline
Fuel Capacity (L)	36
TRANSMISSION
Transmission	CVT
INTERIOR
Seat Material	Fabric
Driver Seat Type & Adjustment	6-Way Manual
Passenger Seat Type & Adjustment	4-Way Manual
Rear # 1 Passenger Seat Type & Adjustment	60:40 Split + Reclining
Power Steering	EPS
Steering Wheel Material	Leather-Wrapped
Parking Brake	EPB + Brakehold
Instrument Panel & Center Cluster	Black Soft Touch Panel + Piano Black
Cup/Bottle Holder	2
Inside Rear View Mirror	Day & Night
Meter Cluster	Digital + Analog
Economy Meter	Hybrid System
EXTERIOR
Headlamps	2-Beam LED Projector
Daytime Running Lights	LED
Front Fog Lamps	Fr: LED
Front Windshield Wiper	Rain-Sensing
Rear Windshield Wiper	Intermittent + Washer
Rear Combination Lamps	LED + Line Guide
Outside Rear View Mirror	Power Adjust + Autofold + Side Turn Signal
Clearance Lamp	With
Front Grille	Chrome + Glossy Black + Matl Grain Black
Rear Spoiler	With
Antenna	Fin
Overfenders	With
FUNCTION
Power Window	Auto Up/Down + Jam Protect
Keyless Entry	With + Smart Entry
Ignition System	Push Start
Airconditioning System	Fr: Auto Dual Zone Climate Control / Rr: A/C Vent
Wireless Charger	With
Data Communication Module	With
Drive Mode Select	Eco + Power + EV
Audio System Type	10" Display Audio
Audio System Speakers	6
Audio System Smartphone Connectivity	Smartphone Linking + Wireless Apple Carplay + Wireless Android Auto + AM/FM + Bluetooth + Voice Command VViFi
Multi-Information Display (MID)	4.2' TFT
Front USB (Type A and Type C)	Type A: 1 / Type C 2
Connectivity	Smartphone Linking + Wireless Apple Carplay + Wireless Android Auto + AM/FM + Bluetooth + Voice Command W'iFi
12v Socket	With
Steering Switches	Audio + Display + Voice + Telephone
CHASSIS
Front/Rear Brake	Ventilated Disc + Solid Disc
Tires / Wheels	215/60 R17 Alloy
Suspension	Fr: MacPherson Strut / Rr: Torsion Beam
Drivetrain	FVVD
Spare Tires	Standard Tire
Brake Type	Fr: Ventilated Disc / Rr: Solid Discs
Stabilizer	With
SAFETY AND SECURITY
Toyota Safety Sense (TSS)	With
SRS Airbags	Driver + Front Passenger + Driver Knee + Driver Side + Passenger Side + Rear Side + Curtain Shield
Anti-Lock Brake System (ABS)	With
Vehicle Stability Control (VSC)	With
Front Seatbelts	3pt. ELR Pretensioner + Force Limiter (xo
Rear Seatbelts	3pt. ELR + Force Limiter (2<3)
Emergency Brake Signal	With
Toyota Vehicle Security System (TVSS)	Toyota Vehicle Security System
Camera	Back Camera (Static)
Clearance and Back Sonar	Fr: 2 / Rr:4
Electronic Brake Distribution (EBD)	With
OTHERS
Meter Gauge	Digital + Analog

DOWNLOAD BROCHURE

GALLERY

PRICELIST

Grade	Engine	Price
1.8 V GR-S HEV	1.8 V GR-S HEV CVT (Emotional Red)	Php1,952,000.00
1.8 V GR-S HEV	1.8 V GR-S HEV CVT (White Pearl)	Php1,947,000.00
1.8 V HV CVT	1.8 V HEV CVT WP (White Pearl)	Php1,810,000.00
1.8 V HV CVT	1.8 V Hybrid CVT	Php1,795,000.00
1.8 G CVT	1.8 G CVT (White Pearl)	Php1,529,000.00
1.8 G CVT	1.8 G CVT	Php1,514,000.00

Details of prices provided here are subject to local conditions and requirements and may, therefore, vary from models available.
Prices are subject to change without prior notice.
Prices are based on SRP and exclusive of LTO and insurance.
